Description
Product characteristics
- Category 5e UTP: Data rate up to 1 GigaBit/s. This allows you to download a 1 Gigabyte file in 8 seconds.
- Sold complete under one catalog number, ready to install.
- Honeycomb design supporting frame for stability and rigidity
Recommendation / Restriction
- Recommended inside use only
The product’s benefits
Installation
- Socket equipped with a tool-less quick connector for intuitive and reliable wiring.
Advantages
- Product delivered with paint and dust protection
- Delivered with screws for flush-mounting or surface-mounting boxes, plastic or metal
Technical characteristics
| Surface mounting | Yes |
| Flush-mounted installation | Yes |
| Duct installation | No |
| Floor box/subfloor mounted | No |
| Type of fastening | Screwing |
| Assembly arrangement | Basic element with full cover plate |
| Type of connector | RJ45 8(8) |
| Suitable for several connectors | 1 |
| Category | 5E |
| Color | Other |
| Connection type | 110 |
| Shielded buses | No |
| Shielded housing | No |
| Separate earthing connection | No |
| With label space | No |
| Separate strain relief | No |
| Outlet direction | Straight |
| With dust cover | Yes |
| Degree of protection (IP) | IP20 |
| Mechanical coding | No |
| Color coding | Yes |
| Device width | 86 mm |
| Device height | 88 mm |
| Device depth | 39 mm |
| Built-in depth | 29.9 mm |
| Degree of impact strength (IK) | IK04 |
| Operating/setting temperature | -5-50 °C |
| Storage temperature | -10-70 °C |
| Antimicrobial treatment | No |
| Mounting method | Surface-mounted/recessed-mounted |
| Horizontal fixing center distance | 60.3-60.3 mm |
| Cable support | Not applicable |
